The basic information J215A
Style :hot chamber die casting machine
Tons : 58Ton
Suitable materials :suitable for zinc ,lead and other low heating point metals
Weight :3500kg
Dosage of fluid metal per shot (zinc): 1.3kg
Package :in nude package for the machine and in wooden cases for asseccories
The specification of J215A
The mould installation drawing
The details of J215A
Locking unit
Locking force kN 580
Closing stroke mm 210
Die height min/max mm 120 - 320
Size of platten mm 456 x 456
Space between tie bars mm 311 x 311
Casting unit
Maximum casting force kN 60
Shot position mm 0 - 50
Casting stroke mm 130
Injection plunger diameter mm 50
Specific injection pressure 60kN
Max. Casting area cm² 189
electrical system of the machine
The machine is equipped with an electrical control cabinet, which is connected to the main switch of the power supply. The voltage range of fluctuation must be limited within 10%, or else a voltage regulator must be installed.
The main circuit of the machine uses 380V AC power supply. The solenoid valve and logical control circuit uses 24V DC power supply, which is converted into by a power rectifier.
Cooling system
The machine is outfitted with a cooling water system, which mainly is used to cool the hydraulic oil and also cool the die-casting mould. The cooling water system consists of cooler, water pipe and backwater sink. You must provide the system with clean fresh water.
Lubrication system
The machine adopts central oil lubrication, so lubricant must be clean. 46# antiwear hydraulic oil is recommended, never substitute it for other lubricants, or the lubricating device may be blocked. The lubrication interval of the lubrication system can be set in the human-machine interface.
After-sales Service
We provide one year warranty for machine .
We provide video ,and when shipment arrives, the seller appoint engineer to buyer's factory for machine commissioning and installation and training workers.
